• experts

RF4.1

RF4.1
GP LA SAFEGUARD RF4.1 (3*GP14AU)

Colour Temperatures:

2200K
2700K
3000K
4000K
6500K

Series SafeGuard RF4.1 Description LED outdoor automotive motion sensor security light, two headlamps Electrical characteristics Input Voltage 4.5VDC (3 x 1.5V C batteries) Operating Voltage 4.5V Standby Current < 100μA Lamp current 350mA Battery Operation 300 days* (Based on 5 operation per day in Auto Mode) Lighting characteristics CCT 4500K-5500K luminous flux / Intensity ≥ 260 lm LED Type 2 x SMD LED Light modes OFF / ON / AUTO Light duration in auto mode 10 s ±3 s Sensors characteristics Sensor Photo sensors & PIR Sensors Sensor Detection Range 8M, 110° Lux Detection Frequency 3 sec per detecion, 1 sec between detection Trigger Lux Value 0-35 Lux Adjustable Physical Characteristics Operating Temperature -20°C to 50°C Storage Temperature -20°C to 50°C Dimension 261.1 (L) x 174.6 (H) x 129.8 (D) mm Weight 433 g Housing Material PC IP Rating IP55

Technical Specification:
•Nominal / Rated Luminous Flux(lm): 260
•Color Temperature: Cool White
•Nominal Correlated Color Temperature: 4000K
•Dimension(W * L): 174.6 * 261.1 * 129.8 mm
