GP LA SAFEGUARD RF2.1 (3*GP15AU)

Colour Temperatures:

2200K
2700K
3000K
4000K
6500K

Series SafeGuard RF2.1 Description LED outdoor automotive motion sensor security light, two headlamps Electrical characteristics Input Voltage 4.5VDC (3 x 1.5V AA batteries) Operating Voltage 4.5V Standby Current < 100μA Lamp current 350mA Battery Life Time 300 days* (Based on 5 operation per day in Auto Mode) Lighting characteristics CCT 4500K-5500K luminous flux / Intensity ≥ 120 lm LED Type 2 x SMD LED Light modes OFF / ON / AUTO Light duration in auto mode 10 s ±3 s Sensors characteristics Sensor Photo sensors & PIR Sensors Sensor Detection Range 8M, 110° Lux Detection Frequency 3 sec per detecion, 1 sec between detection Trigger Lux Value 0-35 Lux Physical Characteristics Operating Temperature -20°C to 50°C Storage Temperature -20°C to 50°C Dimension 194.8 (L) x 128.6 (H) x 113.5 (D) mm Weight 246 g Housing Material PC IP Rating IP55

Technical Specification:
•Nominal / Rated Luminous Flux(lm): 120
•Color Temperature: Cool White
•Nominal Correlated Color Temperature: 4000K
•Dimension(W * L): 128.6 * 194.8 * 113.5 mm
